Construction & Materials
Three grades, one job: resist everything
Virgin PTFE
100% pure PTFE sheet, skived from billet — the broadest chemical resistance of any gasket material, with no filler to compromise it.
Filled PTFE
Glass, carbon, or barium sulfate fiber blended in to cut cold flow and improve creep resistance under sustained bolt load, with only a small trade-off in chemical range.
Expanded PTFE
A biaxially expanded, microporous structure that conforms to flange imperfections and holds a seal at lower bolt torque than solid sheet.
FDA & USP Grades
Food- and pharma-safe formulations available where the application calls for it.
Standards
Cleared for the purest applications
FDA-compliant grades
USP Class VI
ASTM D4894 / D4895
Where It's Used
Wherever the media is unforgiving
Chemical processing
Pharmaceutical
Food & beverage
Acid & caustic service
Ultra-pure piping
Product Line
In stock, or made to your dimensions
Standard sizes are in stock and ready to ship immediately. Need something specific? We manufacture custom PTFE gaskets to your dimensions.
Virgin PTFE sheet1/16″ – 1/4″
Filled PTFE (glass / carbon)
1/16″ – 1/8″
1/16″ – 1/8″
Expanded PTFECustom
